Product Summary

The FDS5680 is an N-Channel MOSFET. The FDS5680 is produced using Fairchild Semiconductors advanced PowerTrench process that has been especially tailored to minimize on-state resistance and yet maintain superior switching performance. These devices are well suited for low voltage and battery powered applications where low in-line power loss and fast switching are required.

Parametrics

FDS5680 absolute maximum ratings: (1)VDSS Drain-Source Voltage: 60 V; (2)VGSS Gate-Source Voltage: ±20 V; (3)ID Drain Current - Continuous: 8 A; (4)PD Power Dissipation for Single Operation: 2.5 W; (5)TJ Tstg Operating and Storage Junction Temperature Range: -55 to +150 ℃.

Features

FDS5680 features: (1)Low gate charge (30nC typical); (2)Fast switching speed; (3)High performance trench technology for extremely low RDS(0N); (4)High power and current handling capability.

Diagrams

FDS5680 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FDS5680
FDS5680
Fairchild Semiconductor
MOSFET SO-8 N-CH 60V
Data Sheet
0-1: $0.99
1-25: $0.88
25-100: $0.71
100-250: $0.61
