Product Summary
The BA6287F-E2 is a reversible-motor driver with a maximum output current of 1.0A. Two logic inputs allow four output modes: forward, reverse, stop (idling), and brake. A built-in power saving circuit suppresses current consumption when the motor is in stop mode.
Parametrics
BA6287F-E2 absolute maximum ratings: (1)power supply volatage: 18V; (2)power dissipation: 650mW; (3)operating temperature: -20 to 75℃; (4)storage temperature: -55 to 150℃; (5)output current: 1000mA.
Features
BA6287F-E2 features: (1)Built-in power saving circuit suppresses the stop mode current dissipation; (2)Output voltage can be set arbitrarily with the VREF pin; (3)Interfaces with TTL devices; (4)Built-in thermal shutdown circuit.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BA6287F-E2 |
ROHM Semiconductor |
Motor / Motion / Ignition Controllers & Drivers REVERSE MOTOR DRIVER 8PIN |
Data Sheet |
|
|
||||||
