SN74HC245NSRG4

octal bus transceiver, 7 V, 20 mA, 12 ns, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.20~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.20~1.00

PartNumber:: SN74HC245NSRG4

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Melody's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-24

From Other Seller

Part Number:SN74HC245NSRG4
US $0.20 - 1.00
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
STK795-820

US $20.00 - 25.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN74HC245NSRG4 is an octal bus transceiver. The SN74HC245NSRG4 is designed for asynchronous two-way communication between data buses. The control-function implementation minimizes external timing requirements. The SN74HC245NSRG4 allows data transmission from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable the device so that the buses are effectively isolated.

Parametrics

SN74HC245NSRG4 absolute maximum ratings: (1)Supply voltage range, VCC: -0.5 V to 7 V; (2)Input clamp current, IIK (VI < 0 or VI > VCC): ±20 mA; (3)Output clamp current, IOK (VO < 0 or VO > VCC): ±20 mA; (4)Continuous output current, IO (VO = 0 to VCC): ±35 mA; (5)Continuous current through VCC or GND: ±70 mA; (6)Storage temperature range, Tstg: -65℃ to 150℃.

Features

SN74HC245NSRG4 features: (1)Wide Operating Voltage Range of 2 V to 6 V; (2)High-Current 3-State Outputs Drive Bus Lines Directly or Up To 15 LSTTL Loads; (3)Low Power Consumption, 80-μA Max ICC; (4)Typical tpd = 12 ns; (5)±6-mA Output Drive at 5 V; (6)Low Input Current of 1 μA Max.
